The number of layers,chambers, and the lamination area can be customized according to customer requirements.
| Model | Specifications | Capacity/laminator/year（MW） |
| Effective laminating area | 2700mm×7800mm | 355 |
| 2700mm×8700mm | 415 | |
| 2700mm×10000mm | 505 | |
| 2700*11500mm | 569 | |
| Temperature range | Room temperature—180℃ | |
| Temperature control accuracy | ±1℃ | |
| Running rate of equipment | >95% | |
| Operation noise | ≤75db | |
| Power requirements | AC380V±10%/50Hz/3phase5wire
AC480V±10%/60Hz/3phase5wire |
|
